CW type Laser Cleaning machineAffordable CW-type Laser Cleaning for Rust Removal
Features
Cleaning with laser light : It can be cleaned where the laser beam can enter, and it is 360세 cleaning without contact, so it is applied to curved surfaces and complex shapes Wide range of cleaning purposes, minimum damage to base material : It can be applied to rust, paint, foreign substances, etc. and minimizes damage to metal base material Efficient and environmental pollution-free cleaning : Eco-friendly laser cleaning with high power energy with fast cleaning speed.
Simple operation method : You can acquire the operation skill within an hour and repeat the same operation with the storage function of the set value Simple maintenance and long service life : No consumables and routine maintenance is completed in 5 minutes, up to 100,000 hours of laser life, stable quality, and excellent reliability Water-cooled chiller built on munt roller : It operates more stably by adopting dual temperature/independent controlled water-cooled chiller. Optimized controller size for good mobility in the factory.
specification
| YFCW1000 | YFCW1500 | YFCW2000 | |
|---|---|---|---|
| Laser Power | 1000W | 1500W | 2000W |
| Weight | 235 | 260 | |
| Output | 5800 | 7300 | 8800 |
| Depth of focus(mm) | 5 | 10 | |
| Fiber Length(m) | 10 (customizable) | 15 (customizable) | |
| Laser Type/Wave (nm) | Fiber Laser / 1064 | ||
| Laser Frequency Range (KHz) | 10000-50000 | ||
| Duty Cycle (%) | 1-100 | ||
| Scan speed (mm/s) | 10000-20000 | ||
| cooling method | Water cooling (18-25°C) | ||
| Coolant Type | deionized water / distilled water / purified water | ||
| Water temperature | 18-23 | ||
| Equipment Size | 1110x743x1238 | ||
| Scan wide | 0-150 | ||
| auxiliary gas | Compressed air (water filtration required) | ||
| Air pressure (MPa) | 0.5-0.8 | ||
| Ambient temperature (°C) | 5-40 | ||
| Cleaning head weight | 0.76 (excluding optical output connectors) | ||
| Working voltage | AC 220V 50Hz/60HZ | ||
